TrueVIS VG3-540 / VG3-640 Series Printers Cutters

VG3 54'' / VG3 64'' COLOR AND PRODUCTIVITY IN PERFECT HARMONY

TrueVIS VG3 Series Printers Cutters: The most advanced generation of TrueVIS

  • FlexFire print heads, TR2 inks, and True Rich Colour combine with user-friendly features to make the VG3
    the ultimate in professional print graphics production.
  • A re-designed chassis, high-quality components, and a variety of media handling improvements make the VG3
    perfect for unattended printing of short runs, long runs, print/cut, and so much more.

TrueVIS VG3 Series Printers Cutters Enhanced features— with you in mind

  • Easy-to-operate, and intuitive 7" LCD touchscreen control panel.
  • Automated media calibration saves time and material.
  • Newly designed, adjustable media take-up unit accommodates rolls of different sizes.
  • One-touch media clasp makes loading media rolls easy for a single operator.

TrueVIS VG3 Series Printers Cutters Expanded colour output

  • Available ink configurations to meet your customers' needs—from brand-accurate colours and
    high-end graphics to high-productivity jobs .
  • Combine Orange and Green inks to push the colour boundaries of digital printing.
  • New CMYK plus light cyan, light magenta, orange, and green inks— combined with
    True Rich Colour 3 deliver vivid, smooth, and colour-rich graphics.

Additional Features

  • VersaWorks 6 RIP Software is included with every VG3—featuring a new True Rich Colour 3 preset,
    new Nearest Colour Finder, and new Variation job function.
  • Roland DG Connect App ready—giving you instant access to important data about print jobs and your business.
  • Various available ink configurations expand your gamut to output rich colour, smooth gradations, and beautiful skin tones.
  • Perforated sheet cut option reduces post-processing with “easy tear” perforations between print jobs.

Specs:

  VG3-540 VG3-640
Size 54 inch 64 inch
Dimension 104 x 29 x52 in.
(2,632 x 748 x1,320 mm)
114 x 29 x 52 in.
(2,886 x 748 x 1,320 mm)

Media Width 11.7 to 54 in.
(297.2 to 1,371 mm)
13.2 to 64 in.
(335.3 to 1,625 mm)

Thickness Max. 39 mil (1.0 mm) with liner, for printing
Max. 15.7 mil (0.4 mm) with liner and 8.6 mil (0.22 mm) without liner, for cutting

Roll outer
diameter
Max. 9.8 in. (250 mm)
Roll weight Max. 77 lb. (35 kg) Max. 99 lb. (45 kg
Core diameter 3 in. (76.2 mm) or 2 in. (50.8 mm)
Ink Colors Ten colours (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black, Orange, Green, White)
Capacity 500 ml pouch (TR2), 250 ml pouch (TR2 White)
Configurations CMYK (TR2)
CMYKLcLmLkOr (TR2)
CMYKLcLmLkWh (TR2)
CMYKLkOrGrWh (TR2)
CMYKLkOrGr (TR2)
CMYKLcLmOrGr (TR2)

Control panel 7 in. touchscreen display
Resolution Max. 1,200 dpi
RIP (included) VersaWorks
Cutting Cut pressure 500 gf
Cut speed 0.39 to 11.8 in/s
(10 to 300 mm/s)
Output
(in standard mode)
4 Colors 310 sq ft hr 327 sq ft hr
8 Colors 127 sq ft hr 132 sq ft hr
Take-up Unit Included



Heavy Load
